MAXIPOWER – 1 KVA to 15 KVA

In stock / Shipping Available

Trimod HE is a VFI Three Phase online double-conversion UPS with PWM High-Frequency technology, modular architecture with the possibility to have N+X redundancy. It has a reduced footprint in the 10 to 80 kW range. Trimod HE is made of individual single-phase modules which are redundant and self-configuring.

Category:

Trimod HE is a VFI Three Phase online double-conversion UPS with PWM High-Frequency technology, modular architecture with the possibility to have N+X redundancy. It has a reduced footprint in the 10 to 80 kW range. Trimod HE is made of individual single-phase modules which are redundant and self-configuring. They deliver a rated power from 10 – 80kW. Batteries are lead-acid, sealed, maintenance-free, valve regulated and arranged inside the UPS as battery modules or in an external battery cabinet.

FEATURES

  • Granular Parallel Architecture
  • Compact footprint
  • Front access
  • 3-Stage charging
  • Multi-colour LCD display
  • Module capacity – 3.4, 5 and 6.7 kVA
  • Independent phase management
  • Battery bank per controller
  • Common battery bank
  • 15 A battery charger module
Range

3 KVA – 80 KVA

Input Voltage Range

395-430 V

Input Frequency

50 Hz

Output Voltage

230 V

Output Frequency

50 Hz

Communication Option

RS 232

Operating Temperature

0-50 °C
